24V Mean Well LPF IP67
LED driver LPF 16D 12 12V 16W IP30
LPF16D12 | Manufacturer: Mean Well | MPN: LPF-16D-12
More info - Brighten Your Home with LED Driver LPF 16D 12V 16W IP30
LED driver LPF 16D 12 12V 16W IP30 Mean Well LPF series IP67 LED power supplies The LED driver LPF 16D 12 is designed for powering LED lighting and moving sign applications. With universal AC input, active PFC function, and a compact size of 148x40x32mm, this driver offers reliable performance. It features a built-in3 in1 dimming function (1~10 VDC or PWM signal or resistance) and protections against short circuit, over current, over voltage, and over temperature. Suitable for dry/damp/wet locations with an efficiency of 83%, this driver comes with a five-year warranty for peace of mind. Technical data: - Input voltage: 90~305 VAC /127~431 VDC - Output: 12V /134A /16 W - Weight:0.21kg
This LED driver LPF 16D 12 12V 16W IP30 is the perfect choice for your Led lighting and moving sign applications. It features universal AC input, active PFC function, 3 in 1 dimming function, IP30/IP67 protection rating and 5 years warranty. With its high efficiency of 83%, this LED driver is UL8750, CSA C22.2 No.250.0-08 approved and suitable for dry/damp/wet locations with dimensions of 148x40x32mm and weight of 0.21kgs.
Suitable for Led lighting and moving sign applications (moving Led display). Suitable for dry/ damp/ wet locations. Universal AC input / Full range (up to305 VAC). Protections: Short circuit/ Over current/ Over voltage/ Over temperature.Built-in active PFC function.Built-in3 in1dimmingfunction(1~10 VDC or PWM signal or resistance). Cooling by free air convection.Fully isolated plastic case.IP30/IP67.Class II power unit,no FG.SAFETY STANDARDS:UL8750,CSA C22.2 No .250 .0 -08 ,EN61347-1 , EN61347-2 -13 independent , EN62384,J61347-1,J61347-2 -13 approved.IP67(optional);Design refer to UL60950-1,TUV EN60950-1.Input voltage:90~305 VAC /127~431 VDC.Input ac current :0 .4 A /115 VAC;0 .25 A /230 VAC ;0 .2 A /277VAC.Output :12V /134A /16 W.Efficiency :83%.Dimensions: 148 ×40×32mm.Weight:0.21kg.
Universal AC input, active PFC function, 3 in 1 dimming function, IP30/IP67 protection rating and 5 years warranty.
Features- Suitable for Led lighting and moving sign applications (moving Led display)
- Suitable for dry/ damp/ wet locations
- Universal AC input / Full range (up to305 VAC)
- Protections: Short circuit/ Over current/ Over voltage/ Over temperature
- Built-in active PFC function
- Built-in3 in1dimmingfunction(1~10 VDC or PWM signal or resistance)
- Cooling by free air convection
- Fully isolated plastic case
- IP30/IP67
-Class II power unit,no FG
-SAFETY STANDARDS:UL8750,CSA C22.2 No .250 .0 -08 ,EN61347 -1 , EN61347 -2 -13 independent , EN62384,J61347 -1,J61347 -2 -13 approved.IP67(optional);Design refer to UL60950 -1,TUV EN60950 -1
List the benefits of the product here.
Technical data- Input voltage: 90~305 VAC /127~431 VDC
- Input ac current : 0 .4 A /115 VAC;0 .25 A /230 VAC ;0 .2 A /277VAC
- Output :12V /134A /16 W
- Efficiency :83%
- Dimensions: 148 ×40×32mm
- Weight:0.21kg
