Ballasts, Electronic, 1-10V
QTi T-E 2x18 42W 230 240V DIM Cfl Quicktronic intelligent
060846 | Manufacturer: Osram | EAN: 4008321060846 | MPN: DT-T-E-1-18-DIM
More info - QTi T-E 2x18 42W Electronic Ballast DIM CFL 1-10V
QTi T-E 2x18 42W 230-240V DIM CFL Quicktronic Intelligent. Dimmable 1-10V electronic control gear for compact fluorescent and fluorescent lamps . Achieve the perfect lighting ambiance with flicker-free dimming capabilities. High efficiency, automatic restart after lamp replacement, and compliance with MINERGIE standard make it an ideal choice for various applications including emergency lighting systems.
Nominal voltage 220 - 240 V
Mains frequency 50 - 60 Hz
DC voltage 154…276 V
Operating frequency 42…140 kHz
Max. no. of ECGs on circuit breaker 10 A 8
Max. no. of ECGs on circuit breaker 16 A 13
Starting time 0.6 s
Length 123 mm
Width 79 mm
Height 33 mm
Mounting hole spacing, length 129.5 mm
Wire preparation length, input side 8.5…9.5 mm
Wire preparation length, output side 8.5…9.5 mm
Ambient temperature range –10…+50 °C
Optional cable clamp, see chapter ECG mountings - cable clamp
Dimming interface 1…10 V
Dimming range 3…100%
Dimmable Yes
Suitable for fixtures with prot. class I
End of lamp life safety shutdown EOL T.2
Approval marks - approval VDE / VDE-EMC / ENEC 10 / EL / GOST / RCM / CCC
EEI - Energy Label A1 BAT
Standards acc. to EN 61347-2-3/acc. to EN 60929/acc. to EN 55015: 2006 + A1: 2007/acc. to EN 61000 - 3-2/acc. to EN 61547
Benefits
• Same luminous flux with direct and alternating current
• Perfect lamp start for applications with motion sensors
• Dimming of amalgam lamps without flickering or reduced lifespan
• Very high efficiency thanks to cut-off technology
• Automatic restart after lamp replacement
• ECGs comply with MINERGIE standard due to very low standby consumption
• Configurable emergency power characteristics
Applications
• Suitable for use in emergency lighting systems as per EN 50172/DIN VDE 0108-100
• Suitable for luminaires of protection class I
