Ballasts, Electronic
ELXs 116.900 1x4-16W TC-SEL TC-DEL TC-DD T5 T8
188661 | Manufacturer: Vossloh Schwabe | EAN: 8712251072690 | MPN: 188661
More info - ELXs 116.900 Electronic Ballast 1x4-16W TC-SEL TC-DEL TC-DD T5 T8
ELXs 116.900 is an electronic ballast designed for compact fluorescent lamps, T5 and T8 lamps. This built-in ballast features a heat-resistant polyamide casing and push-in terminals with push-button for easy installation. With RFI suppression and EOL shut down approved acc. to EN 61347 Test 2, it ensures reliable performance. Suitable for luminaires of protection class I and II, this ballast has fixing slots for screws M4 and is ideal for lighting systems with high switching frequency (>5/day). Experience efficient illumination with ELXs 116.900!
Electronic built-in ballast
Casing: heat-resistant polyamide
Power factor: approx. 0.6 (depending on the lamp output)
DC voltage operation: 198 - 264 V
Push-in terminals with push-button: 0.5 - 1.5 mm²
RFI-suppressed
For luminaires of protection class I and II
Degree of protection: IP20
Fixing slots for screws M4
For lighting systems with high switching frequency ( > 5/day)
EOL shut down approved acc. to EN 61347 Test 2
Lamp type: TC-SEL, TC-DEL, TC-DD, T5, T8
Output [W]: 5, 7, 9, 11 for compact fluorescent lamps TC-SEL (2G7)
Output [W]: 10 for compact fluorescent lamps TC-DEL (G24q-1)
Output [W]: 10, 16 for compact fluorescent lamps TC-DD (GR10q)
Output [W]: 4, 6, 8, 13 for T5 lamps (G5)
Output [W]: 16 for T8 lamps (G13)
Lamp number: 1
Voltage AC [V]: 220 - 240
Frequency [Hz]: 50 - 60
Ambient temperature ( °C) –15 to 55
