ELXs 121.904 1x14 21W 1x13 18W TC-DEL TEL T5
188664 | Manufacturer: Vossloh Schwabe | EAN: 8712251072942 | MPN: 188664
More info - ELXs 121.904 Electronic Ballast for T5 Lamp
ELXs 121.904 is a versatile electronic ballast designed for compact fluorescent lamps and T5 lamps. With its heat-resistant polyamide casing, push-in terminals, and RFI suppression, this ballast ensures reliable performance. Suitable for protection class I and II luminaires, it offers IP20 degree of protection and can handle high switching frequencies. Approved for EOL shut down according to EN 61347 Test 2, it supports TC-DEL/-TEL (G24q-1/GX24q-1) compact fluorescent lamps with outputs of 13W or 18W, as well as T5 lamps (G5) with outputs of 14W or 21W. Voltage range: AC [V] -220 to 240; Frequency [Hz]:50 -60; Ambient temperature (°C): -15 to +55.
Electronic built-in ballast
Casing: heat-resistant polyamide
Power factor: approx. 0.6 (depending on the lamp output)
DC voltage operation: 198 - 264 V
Push-in terminals with push-button: 0.5 - 1.5 mm²
RFI-suppressed
For luminaires of protection class I and II
Degree of protection: IP20
Fixing slots for screws M4
For lighting systems with high switching frequency ( > 5/day)
EOL shut down approved acc. to EN 61347 Test 2
Lamp type: TC-DEL/-TEL, T5
Output [W]: 13, 18 for compact fluorescent lamps TC-DEL/-TEL (G24q-1/GX24q-1)
Output [W]: 14, 21 for T5 lamps (G5)
Lamp number: 1
Voltage AC [V]: 220 - 240
Frequency [Hz]: 50 - 60
Ambient temperature ( °C) –15 to 55
