Z2000S Ignitor
404320 | Manufacturer: Vossloh Schwabe | EAN: 4050732404320 | MPN: 140432
More info - Z2000S Electronic Ignitor for HS HI Lamp
Upgrade your lighting system with the Z2000S electronic superimposed ignitor. Designed for HI lamp up to 2000W, this standard version ignitor ensures a smooth and reliable ignition process. With a voltage range of 220-240V and a maximum lamp current of 20A, it guarantees optimal performance. Its compact size and easy installation make it suitable for luminaires of protection class I and II. Illuminate your space with confidence using the Z2000S electronic superimposed ignitor.
Elevate your lighting experience to new heights with the Z2000S electronic superimposed ignitor. This cutting-edge ignitor is designed specifically for HI lamps up to 2000W, ensuring a smooth and reliable ignition process every time.
Optimal Performance GuaranteedThe Z2000S ignitor boasts a voltage range of 220-240V and a maximum lamp current of 20A, providing you with optimal performance that exceeds expectations. Say goodbye to flickering lights or delayed start-ups - this ignitor delivers consistent and efficient illumination.
Sleek Design for Easy InstallationThe compact size of the Z2000S makes it incredibly easy to install in luminaires of protection class I and II. With its user-friendly design, you can effortlessly upgrade your lighting system without any hassle or complications.
Technical Specifications:- Voltage AC: 220 - 240 V
- Frequency: 50 - 60 Hz
- Max. Lamp Current: 20 A
- Internal Loss:<6 W
- Inherent Heating:<30K
- Ignition Voltage: 4 -5 kV
- Loading Capacity: 20-100 pF
The Z2000S electronic superimposed ignitor features screw terminals suitable for wire sizes ranging from 0.75mm² to2.5mm², ensuring secure and reliable connections. Its fastening mechanism includes a male nipple with a pre-assembled washer and nut for added convenience.
With a maximum permitted casing temperature of 105°C, the Z2000S ignitor is built to withstand demanding environments without compromising performance or safety. You can trust this ignitor to deliver exceptional results even in challenging conditions.
Elevate Your Lighting Experience TodayUpgrade your lighting system with confidence using the Z2000S electronic superimposed ignitor from Vossloh Schwabe. Illuminate your space like never before and enjoy the benefits of superior performance, reliability, and ease of installation. Don't settle for ordinary lighting - choose the Z2000S ignitor for extraordinary illumination.
