Mean Well Dali interface
LED driver LCM 60 2 90V 60W IP20
LCM60 | Manufacturer: Mean Well | MPN: LCM-60
More info - Brighten Your Home with LED Driver LCM 60 2 90V 60W IP20
Introducing the Mean Well LED driver LCM 60 2 90V 60W IP20 for powering your LED setups. This driver offers selectable output current levels and built-in active PFC function for efficient power usage. With robust protections against short circuits and over-temperature, it ensures safety and longevity. The compact design with an IP20 rating makes it suitable for various applications, from residential to industrial settings. Enjoy precise brightness control, wide input voltage range, and enhanced dimming capabilities with this reliable LED power supply . Upgrade your lighting systems effortlessly with the Mean Well LED driver LCM 60 2 90V 60W IP20 today!
Introducing Our LED Driver LCM 60 2 90V 60W IP20 - Illuminating Brilliance
Are you in search of an advanced and efficient LED driver that can enhance your indoor lighting experience? Look no further! Our LED driver LCM 60 2 90V 60W IP20 is a cutting-edge solution designed to elevate your lighting systems to new heights. In this comprehensive product description, we'll delve into its features, benefits, technical specifications, and applications, allowing you to make an informed decision about your lighting needs.
Illuminate Your Space with Confidence
Description
Our LED driver LCM 60 2 90V 60W IP20 is the perfect choice for those seeking reliability and versatility in their lighting systems. This advanced driver boasts a range of features that make it stand out in the market. With its output current level selectable via a DIP switch, you have complete control over the brightness of your LED lights. Additionally, it comes equipped with a built-in active PFC (Power Factor Correction) function, ensuring efficient power utilization.
Unmatched Performance and Safety
Features
- Output current level selectable via DIP switch
- Built-in active PFC function
- Wide input voltage range of 180~295 VAC
- Robust protections against short circuits, overvoltage, and over-temperature
- Effective cooling through free air convection
- Fully isolated plastic case for enhanced safety
- Class II power unit with no FG (Functional Ground)
- Built-in 0~10 VDC and PWM signal dimming function
- Integrated 12 V / 50 mA auxiliary output
- IP20 rating for protection against dust and foreign objects
- Ultra-low no-load power consumption (<1 W)
- Temperature compensation function with external NTC (Negative Temperature Coefficient)
- Power supplies synchronization function, allowing connection of up to 10 units simultaneously
- Backed by a confidence-inspiring 3-year warranty
Meeting Stringent Safety Standards
Technical Data
- Compliant with safety standards: UL8750, ENEC EN61347-1, EN61347-2-13, EN62384, GB19510.14, GB19510.1
- Input voltage range: 180
295 VAC / 254417 VDC - Input AC current: 0.32 A / 230 VAC, 0.27 A / 277 VAC
- Output options: 2
90 VDC/500 mA, 290 VDC/600 mA, 286 VDC/700 mA, 267 VDC/900 mA, 257 VDC/1050 mA, 242 VDC/1400 mA - Input frequency range: 47~63Hz
- Outstanding efficiency rating of 92%
- Compact dimensions measuring 123.5 × 81.5 × 23 mm
- Lightweight design, weighing only 0.24 kg
Endless Possibilities
Applications
Our LED driver LCM 60 2 90V 60W IP20 is incredibly versatile and can be used in various lighting applications. Whether you're planning to upgrade your residential lighting, illuminate commercial spaces, or enhance industrial settings, this driver is up to the task. Its adaptability and wide voltage input range make it suitable for a multitude of scenarios.
Benefits That Shine Bright
Benefits
- Achieve precise brightness control with selectable output levels
- Enjoy efficient power usage with the built-in active PFC function
- Wide input voltage range accommodates diverse power sources
- Robust protections ensure longevity and safety
- Compact, lightweight, and easy to install
- Enhanced dimming capabilities for customized lighting experiences
- IP20 rating for added protection
- Energy-efficient with minimal no-load power consumption
- Temperature compensation function for consistent performance
- Easily synchronize multiple units for larger installations
- Backed by a 3-year warranty for peace of mind
Technical Excellence
Technical Electrical Data
- Input voltage range: 180
295 VAC / 254417 VDC - Input AC current: 0.32 A / 230 VAC, 0.27 A / 277 VAC
- Output options:
- 2~90 VDC/500 mA
- 2~90 VDC/600 mA
- 2~86 VDC/700 mA
- 2~67 VDC/900 mA
- 2~57 VDC/1050 mA
- 2~42 VDC/1400 mA
- Input frequency range: 47~63Hz
- Efficiency: Impressive 92%
- Dimensions:123.5 × 81.5 × 23 mm
- Weight: Only 0.24 kg
Light the Way with Confidence
Conclusion
In conclusion, our LED driver LCM 60 2 90V 60W IP20 is your key to brighter, more efficient, and customizable lighting solutions. With advanced features, robust safety measures, and a track record of meeting industry standards, this driver is the ideal choice for all your indoor LED lighting needs. Whether you're a homeowner looking to revamp your living space or a business owner seeking to create an inviting ambiance, our LED driver is your reliable partner in illumination. Don't miss the opportunity to elevate your lighting experience; choose our LED driver LCM 60 2 90V 60W IP20 today!
