R111 CDM 70W 930 GX8.5 40D Elite

Cap-Base GX8.5 [ GX8.5]
Operating Position UNIVERSAL [ Any or Universal (U)]
Life To 5% Failures 8000 h
Life To 10% Failures 9500 h
Life To 20% Failures 10500 h
Life To 50% Failures 12000 h
Switching Cycle 1050X
Color Code 930 [ CCT of 3000 K]
Beam Angle 40°
Luminous Intensity (Min) 6500 cd
Luminous Intensity 8500 cd
Beam Description Flood
Color Designation Warm White (WW)
Lumen Maintenance 12000 h 70%
Lumen Maintenance 2000 h 90%
Lumen Maintenance 4000 h 85%
Design Mean Lumens 3100 lm
Chromaticity Coordinate X 0.441
Chromaticity Coordinate Y 0.397
Correlated Color Temperature 3000 K
Luminous Efficacy (rated) 50 lm/W
Color Rendering Index (Min) 89
Color Rendering Index 92
LLMF At End Of Nominal Lifetime 70%
Luminous Flux In 90 °Cone (Rated) 3550 lm
Power (Rated) 70 W
Re-Ignition Time (Min) (Max) 15 min
Warm Up Time To 60% Light 120s
Ignition Time (Max) 30s
Voltage (Max) 98 V
Voltage (Min) 80 V
Voltage 89 V
Dimmable No
Run-Up Time 90% (Max) 3 min
Bulb Finish Reflector
Energy Efficiency Label (EEL)A
Mercury (Hg) Content 6.6 mg
Energy Consumption kWh/1000 h 80 kWh

Benefits
• Crisp white sparkling light
• Easy installation
• Less glare, comfort for shoppers and staff

Features
• High lamp efficacy
• Long lamp lifetime compared to incandescent and halogen lamps
• The ceramic discharge tube is optimally positioned and stable in the reflector
• UV-block burner capsule
• Anti-glare cap design

Applications
• Accent and decorative lighting: display lighting with sparkling, theatrical effects, even in surroundings with very high background ambient light levels, such as shops windows
• General lighting: in downlighters, a warm and comfortable atmosphere can be created

General safety informations
