Ballasts, Electronic
ELXc 280.538 2x55W 2x80W TC-L T5
188619 | Manufacturer: Vossloh Schwabe | EAN: 8712251072614 | MPN: 188619
More info - ELXc 280.538 Electronic Ballast for 2x55W and 2x80W TC-L T5
ELXc 280.538 2x55W 2x80W TC-L T5 Electronic Ballast is a high-performance solution for compact fluorescent lamps and T5 lamps. With its metal casing, RFI suppression, and IP20 protection, it ensures reliable operation in lighting systems with frequent switching. This ballast supports two TC-L lamps (2G11) at 55W each or two T5 lamps (G5) at 80W each. Designed for luminaires of protection class I, it operates on AC voltage of 220-240V with a frequency range of 50-60Hz. Perfect for various applications with an ambient temperature range from -15°C to 55°C.
Electronic built-in ballast
Casing: metal
Power factor: > 0.96
DC voltage for operation: 176 - 264 V, for ignition: 198 - 264 V (ELXc 180.866, 280.538: DC voltage cannot be reduced to 176 V)
Push-in terminals: 0.5 - 1 mm²
For the automatic luminaire wiring: IDC terminals for leads H05 V-U 0.5
RFI-suppressed
For luminaires of protection class I
Degree of protection: IP20
For lighting systems with high switching frequency ( > 5/day)
EOL shut down approved acc. to EN 61347 Test 2
Lamp type: TC-L, T5
Output [W]: 2 × 55, 2 × 80 for compact fluorescent lamps TC-L (2G11)
Output [W]: 2 × 80 for T5 lamps (G5)
Lamp number: 2
Voltage AC [V]: 220 - 240
Frequency [Hz]: 50 - 60
Ambient temperature ( °C) –15 to 55
