Ballasts, Electronic
ELXs 121.901 1x13 21W TC-DEL TEL T5
188663 | Manufacturer: Vossloh Schwabe | EAN: 8712251072898 | MPN: 188663
More info - ELXs 121.901 Electronic Ballast for 21W TC-DEL T5
ELXs 121.901 1x13 21W TC-DEL TEL T5 : Compact and efficient electronic ballast for TC-DEL/-TEL and T5 lamps. Perfect for high switching frequency lighting systems. With a power factor of approximately 0.6, this RFI-suppressed ballast operates on a wide DC voltage range of 198 - 264V. Suitable for protection class I and II luminaires, it offers EOL shut down approved acc. to EN 61347 Test 2. Experience reliable performance with this IP20 rated ballast featuring push-in terminals and fixing slots for easy installation in your lighting setup.
Electronic built-in ballast
Casing: heat-resistant polyamide
Power factor: approx. 0.6 (depending on the lamp output)
DC voltage operation: 198 - 264 V
Push-in terminals with push-button: 0.5 - 1.5 mm²
RFI-suppressed
For luminaires of protection class I and II
Degree of protection: IP20
Fixing slots for screws M4
For lighting systems with high switching frequency ( > 5/day)
EOL shut down approved acc. to EN 61347 Test 2
Lamp type: TC-DEL/-TEL, T5
Output [W]: 13, 18 for compact fluorescent lamps TC-DEL/-TEL (G24q-1/GX24q-1, G24q-2/GX24q-2)
Output [W]: 14, 21 for T5 lamps (G5)
Lamp number: 1
Voltage AC [V]: 220 - 240
Frequency [Hz]: 50 - 60
Ambient temperature ( °C) –15 to 55
