G12
G12 MasterColour CDM-T 150W 942
200051 | Manufacturer: Philips | EAN: 8711500200051 | MPN: 928084605131
More info - MasterColour CDM-T 150W 942 Premium G12 Lamp
The G12 Metal Halide Lamp MasterColour CDM-T 150W 942 is a single-ended, compact, high-efficiency discharge lamp. With a stable color over its lifetime and a crisp, sparkling light, this lamp offers beautiful sparkle and reliable performance. It has a long life compared to incandescent and halogen lamps, resulting in low operating costs. The relatively low heat output enhances comfort for shoppers and staff. Additionally, it is UV-Block for reduced fading risks. Perfect for shops, offices, public buildings, as well as decorative outdoor lighting applications like floodlighting and pedestrian areas.
Cap-Base G12
Bulb T19 [T 19 mm]
Bulb Finish Clear
Operating Position any [Any or Universal (U)]
Life to 5% failures EL 9000 h
Life to 10% failures EL 10000 h
Life to 20% failures EL 11000 h
Life to 50% failures EL 12000 h
Color Code 942 [CCT of 4200 K]
Color Rendering Index 96 Ra8
Color Designation Cool White
Color Temperature 4200 K
Color Temperature Technical 4050K
Luminous Flux Lamp EL 12700 lm
Luminous Efficacy Lamp EL 85 lm/W
Lumen Maintenance EL 2000 h 85%
Lumen Maintenance EL 5000 h 80%
Lumen Maintenance EL 10000 h 70%
Design Mean Lumens EL 10800 lm
Chromaticity Coordinate X 0.375 -
Chromaticity Coordinate Y 0.363 -
Lamp Wattage 150 W
Lamp Voltage 90 V
Lamp Current EM 1.9 A
Lamp Current EL 1.7 A
Ignition Time 30 (max) s
Run-up time 90% 3 (max) min
Ignition Peak Voltage 3500 (min) V
Re-ignition Time [min] 15 (max) min
Dimmable No
Energy Efficiency Label (EEL) A+
Mercury (Hg) Content 10.4 mg
Energy consumption kWh/1000 h 165 kWh
Damage Factor D/fc 0.4 (max) -
PET (NIOSH) 8 (min) h500 lx
Cap-Base Temperature 280 (max) °C
Pinch Temperature 350 (max) °C
Bulb Temperature 650 (max) °C
Reference Length A 96 (max) mm
Overall Length C 110 (max) mm
Diameter D 20 (max) mm
Light Center Length L 55 (min), 56 (nom), 57 (max) mm
Arc Length O 8 mm
Light Center Length L [inch] 2.21875 in
Overall Length C [inch] 4.34375 (max) in
Diameter D [inch] 0.75 in
Benefits
• Beautiful sparkle, reliable life
• Stable color impression over lifetime
• High lamp efficacy results in low operating costs and low heat generation
• Long lamp life compared with incandescent and halogen lamps
• Relatively low heat output enhances comfort for shoppers and staff
• All types are UV-Block for reduced fading risks
Features
• Crisp white light
• Superior color quality
• Allows small-size luminaires designs that give high beam intensities
Applications
• Shops and shop windows, offices and public buildings
• Decorative outdoor: floodlighting and pedestrian areas
