G12
G12 MasterColour CDM-T 70W 830
196996 | Manufacturer: Philips | EAN: 8711500196996 | MPN: 928082305125
More info - MasterColour CDM-T 70W 830 Premium G12 Lamp
The G12 Metal Halide Lamp MasterColour CDM-T 70W 830 is a single-ended, compact, high-efficiency discharge lamp. It provides a stable color over its lifetime and emits a crisp, sparkling light. With its long lifespan and low heat generation, this lamp offers cost-effective operation and enhanced comfort for shoppers and staff. Its UV-Block feature reduces fading risks, making it ideal for shops, offices, public buildings, as well as decorative outdoor lighting applications.
Cap-Base G12
Bulb T19 [T 19 mm]
Bulb Finish Clear
Operating Position any [Any or Universal (U)]
Life to 5% failures EL 9000 h
Life to 10% failures EL 10000 h
Life to 20% failures EL 11000 h
Life to 50% failures EL 12000 h
Color Code 830 [CCT of 3000 K]
Color Rendering Index 84 Ra8
Color Designation Warm White
Color Temperature 3000 K
Color Temperature Technical 3070K
Luminous Flux Lamp EL 6500 lm
Luminous Efficacy Lamp EL 89 lm/W
Lumen Maintenance EL 2000 h 85%
Lumen Maintenance EL 5000 h 80%
Lumen Maintenance EL 10000 h 70%
Design Mean Lumens EL 5250 lm
Chromaticity Coordinate X 0.432 -
Chromaticity Coordinate Y 0.395 -
Lamp Wattage 70 W
Lamp Voltage 88 V
Lamp Current EM 0.98 A
Lamp Current EL 0.87 A
Ignition Time 30 (max) s
Run-up time 90% 3 (max) min
Ignition Peak Voltage 3500 (min) V
Re-ignition Time [min] 15 (max) min
Dimmable No
Energy Efficiency Label (EEL) A+
Mercury (Hg) Content 4.5 mg
Energy consumption kWh/1000 h 80 kWh
Damage Factor D/fc 0.3 (max) -
PET (NIOSH) 8 (min) h500 lx
Cap-Base Temperature 280 (max) °C
Pinch Temperature 350 (max) °C
Bulb Temperature 500 (max) °C
Reference Length A 90 (max) mm
Overall Length C 103 (max) mm
Diameter D 20 (max) mm
Light Center Length L 55 (min), 56 (nom), 57 (max) mm
Arc Length O 7 mm
Light Center Length L [inch] 2.21875 in
Overall Length C [inch] 3.9375 (max) in
Diameter D [inch] 0.75 in
Benefits
• Beautiful sparkle, reliable life
• Stable color impression over lifetime
• High lamp efficacy results in low operating costs and low heat generation
• Long lamp life compared with incandescent and halogen lamps
• Relatively low heat output enhances comfort for shoppers and staff
• All types are UV-Block for reduced fading risks
Features
• Crisp white light
• Superior color quality
• Allows small-size luminaires designs that give high beam intensities
Applications
• Shops and shop windows, offices and public buildings
• Decorative outdoor: floodlighting and pedestrian areas
